1000W IPG RAS-3015 Laser Cutting Machine Parameters Introduction

KRRASS Fiber Laser Cutting Machine can be used to cut a wide range of materials. Fiber lasers are more effective than other laser sources for cutting highly reflective materials e.g. aluminium alloys, cooper, brass…etc. Varied thicknesses (up to 22 mm of mild steel) can be cut with efficiency and quality. Productivity increases particularly with thin sheet metal with almost zero maintenance and 70% less cutting cost compared to CO2 laser cutting machine.

General Features:

1000W Fiber Laser Cutting Machine

70% low electricity consumption comparison with CO2 Laser
Up to 300% faster cutting
High wall plug efficiency (>%30)
Flexible beam path
Maintenance free
Copper, brass cutting ability
High output power
High optical quality
Compact size
Reliability

Standard Equipments:

IPG YLS-1000W Ytterbium Laser Resonator
Linear Driven X, U and Y Axes
High Rigid Frame
Empower or FAGOR CNC Controller
Precitec Cutting Head
Lantek Software
Shuttle Table
Chiller Unit
Proportional Gas and Piping System
Dust Filter
Compressor
Conveyor for Scraps

Laser Cutting Machine Parameters:

No.TypeRAS-3015
1Max Cutting Size (mm)1500×3000
2Max Height of The Workpiece (mm)90
3Effective TravelX Axis (mm)1505
Y Axis (mm)3005
Z Axis (mm)150
4Positional AccuracyX Axis (mm)±0.04
Y Axis (mm)±0.04
Z Axis (mm)±0.01
5Repeated Positioning AccuracyX Axis (mm)±0.03
Y Axis (mm)±0.03
Z Axis (mm)±0.005
6Re-positioning SpeedX Axis (m/min)110
Y Axis (m/min)110
Z Axis (m/min)110
7Accelerated Speed (G)1.5
8The Laser Power(W)2000
9Level of ProtectionIP54
10Total Weight(KG)5200
11Boundary Dimension L×W×H(mm)4600X3200X1800
