W11 3-Roll Plate Roller Machine

KRRASS High Standard 3-Roll Plate Roller Machine
The W11 Series plate roller machine is mighty and uses a pyramidal linear guide for bending rollers, which enables it to achieve the best bending results without guaranteed power loss. In the plate roller machine model W11, all three rollers use independent hydraulic gear motors directly coupled to the rolling roller shaft, which can ensure the superiority of torque and speed of these plate roller machines.


Standard Manual Drop-End

Optional Control Panel with digital read-out

Tailored-made Plate Bending Machine
Standard Equipment
- Two motorised rolls
- Induction hardened rolls
- Polished roll surface
- Motorised pre-bending and bending
- Bending roll tilt
- Rolls with extensions for bending profiles
- Mobile pedal controls
- Emergency barrier around the machine
- CE certified machine
Optional features
- Profile section bending rings
- Numerical controls
- Version with vertical rolls
- Central and side supports
- Machine ready for hot rolling
- Version with planetary guides (3HEP)
- Special colours
Technical Parameter of Plate Bending Machine
Name | Max Rolling Thickness | Max Rolling Width(mm) | Min Rolling Diameter(N/mm) | Yield Limit(N/mm2) | Rolling Speed(m/min) | Upper Roller Diameter(mm) | Lower Roller Diameter(mm) | Lower Roller Center Distance(mm) | Main Motor Power(Kw) | Length(mm) | Width(mm) | Height(mm) | Weight(Kg) | |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
<450N/mm2 | <700N/mm2 | |||||||||||||
W11-4/1500 | 4 | 2.5 | 1500 | 187.5 | 245 | 5 | 150 | 140 | 200 | 4 | 3050 | 860 | 1070 | 1700 |
W11-4/2000 | 4 | 2.5 | 2000 | 200 | 245 | 5 | 160 | 150 | 220 | 4 | 3500 | 950 | 1200 | 2000 |
W11-6/1500 | 6 | 4 | 1500 | 200 | 245 | 5 | 160 | 150 | 220 | 4 | 3000 | 750 | 1200 | 2200 |
W11-6/2000 | 6 | 4 | 2000 | 212.5 | 245 | 5 | 170 | 160 | 220 | 5.5 | 3500 | 900 | 1150 | 2500 |
W11-6/2500 | 6 | 4 | 2500 | 225 | 245 | 4.5 | 180 | 170 | 250 | 5.5 | 4050 | 910 | 1150 | 2600 |
W11-8/1500 | 8 | 5 | 1500 | 212.5 | 245 | 5 | 170 | 160 | 220 | 5.5 | 300 | 900 | 1150 | 2400 |
W11-8/2000 | 8 | 5 | 2000 | 225 | 245 | 4.5 | 180 | 170 | 250 | 5.5 | 3500 | 850 | 1150 | 2500 |
W11-8/2500 | 8 | 5 | 2500 | 300 | 245 | 4.5 | 240 | 180 | 280 | 7.5 | 4350 | 950 | 1250 | 4000 |
W11-12/2000 | 12 | 8 | 2000 | 300 | 245 | 4.5 | 240 | 180 | 280 | 7.5 | 3900 | 1200 | 1350 | 3500 |
W11-12/2500 | 12 | 8 | 2500 | 325 | 245 | 4.5 | 260 | 220 | 320 | 11 | 4300 | 1285 | 1400 | 5300 |
W11-12/3000 | 12 | 8 | 3000 | 350 | 245 | 4 | 280 | 240 | 360 | 11 | 5100 | 1350 | 1350 | 7500 |
W11-16/2000 | 16 | 10.5 | 2000 | 325 | 245 | 4.5 | 260 | 220 | 320 | 11 | 3850 | 1250 | 1300 | 4800 |
W11-16/2500 | 16 | 10.5 | 2500 | 350 | 245 | 4 | 280 | 240 | 360 | 11 | 4500 | 1600 | 1450 | 6700 |
W11-16/3000 | 16 | 10.5 | 3000 | 425 | 245 | 4 | 340 | 270 | 440 | 15 | 5700 | 1600 | 1750 | 10300 |
W11-20/2000 | 20 | 13 | 2000 | 350 | 245 | 4 | 280 | 240 | 360 | 11 | 4000 | 1450 | 1450 | 6500 |
W11-20/2500 | 20 | 13 | 2500 | 425 | 245 | 4 | 340 | 270 | 440 | 15 | 4700 | 1530 | 1680 | 9300 |
W11-25/2000 | 25 | 16.5 | 2000 | 425 | 245 | 4 | 340 | 270 | 440 | 15 | 4300 | 1600 | 1650 | 8600 |
W11-25/2500 | 25 | 16.5 | 2500 | 462.5 | 245 | 4 | 370 | 280 | 480 | 22 | 5780 | 1650 | 1962 | 11000 |
W11-30/2000 | 30 | 20 | 2000 | 462.5 | 245 | 4 | 370 | 280 | 480 | 22 | 5280 | 1650 | 1962 | 10000 |
W11-30/2500 | 30 | 20 | 2500 | 525 | 245 | 4 | 420 | 360 | 550 | 30 | 5240 | 1750 | 2070 | 16000 |
W11-30/3000 | 30 | 20 | 3000 | 187.5 | 245 | 4 | 150 | 390 | 600 | 30 | 5700 | 1750 | 2300 | 18500 |
W11-40/2500 | 40 | 26.5 | 2500 | 625 | 245 | 4 | 500 | 400 | 600 | 37 | 5300 | 1900 | 2400 | 20000 |
